LINOVISION PoE Splitter Selection Guide
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
Learn more >
|
||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | POE-SP24V | POE-SP24V(Pro) | POE-SP01 (2 pack) |
POE-SP01G (2 pack) |
POE-SP01P (2 pack) |
POE-SP01C (2 pack) |
POE-USBC01 | POE-USBC6001G | POE-SP1224POE | POE-SP1224F | POE-SP30 | POE-SP02BT-POE | POE-SP02BTV | |
| PoE Input | IEEE803.2af/at Max 30W |
IEEE803.2af/at Max 30W |
IEEE803.2af/at Max 30W |
IEEE803.2af/at Max 30W |
IEEE803.2af/at Max 30W |
IEEE803.2af Max 15W |
IEEE802.3af/at Max 20W |
IEEE802.3af/at Max 30W |
IEEE803.2af/at Max 30W |
IEEE802.3af/at/bt Max 30W | IEEE803.2af/at Max 30W |
IEEE802.3af/at/bt Max 90W |
IEEE802.3af/at/bt Max 90W |
|
| Output1 | Passive 24V POE | Passive 24V POE | 12V DC | 12V DC | 12V DC | USB-C output | USB-C output | USB-C output | 12/24V DC | 12/24V DC switchable | 5/9/12/18V DC switchable | 5/9/12/24V DC switchable | 24V DC | |
| Output2 | / | / | / | / | / | / | / | / | Passive POE 12/24V | 1*Gigabit SFP Port, 1*Gigabit Dataput | / | 48V POE (Active PoE） |
3 ~ 36V DC adjustable |
|
| Network Speed | Gigabit | Gigabit | 10/100Mbps | Gigabit | 10/100Mbps | 10/100Mbps | 10/100Mbps | Gigabit | Gigabit | Gigabit | Gigabit | Gigabit | Gigabit | Gigabit |
| Waterproof | ✔ | / | / | / | ✔ | / | / | / | / | / | / | / | / | |
| Dimension | / | 2.36x0.99x4.06"(60x25x103mm) | 3.14x1.10x0.82"(80x28x21mm) | 3.14x1.10x0.82"(80x28x21mm) | 4.1x0.7"(105x17mm) | 3.14x1.10x0.82"(80x28x21mm) | 3.54x1.61x0.94"(90x41x24mm) | 1.02x1.81x4.13"(26x46x105mm) | 3.27x2.48x1.02"(83x63x25.8mm) | 3.27x2.48x1.02"(83x63x25.8mm) | 3.07x2.87x1.10"(78x73x28mm) | 4.69x3.37x1.1"(119x85.5x28mm) | 3.74x2.75x1.14"(95x70x29mm) | |
| Installation | / | / | / | / | / | / | / | / | DIN-Rail/ Wall-Mount |
DIN-Rail | Wall-Mount | DIN-Rail/ Wall-Mount |
DIN-Rail/ Wall-Mount |
|
